Product and packaging similar. Subject to modifications and errors.
Casual
HDMI™ / DVI adapter cable
video adapter between HDMI™ and DVI-D
Enjoy movies and games in clear, high resolution, and dazzling quality. What does this cable do to an audio video signal? Nothing. It is, however, precisely this feature which proves its quality. Thanks to pure materials, precise processing, and modern technology, it transfers digital video signals between HDMI™ and DVI-D devices. Therefore, you can be sure that you get the experience exactly as it was meant to be.
- transmits digital video signals in both directions
- pure copper conductor and 2-way shielding for clear signal quality
- High-speed HDMI™ for 3D and Ultra HD up to 4K @ 50/60 Hz (2160 p)
- 24 carat gold-plated contacts for minimum transmission resistance
- A permanently jerk-free picture is guaranteed by the double shielding of aluminium foil and copper braiding
- Long-term usable due to flexible and robust PVC jacket, which can be bent optimally and simplifies the laying of the cable
- Even after many years, crystal-clear picture and sound quality and rust-free connections thanks to 24-carat gold-plated connectors
General
| Operating temperature up to |
80 °C |
| Warranty |
10 years |
| Markings |
WEEE, CE, ULTRAHD 4K@50/60 Hz, HDMI™ High Speed |
| Consumption Unit |
1 pc. in cardboard box |
| Operating temperature from |
-10 °C |
| Packaging type |
Retail Box |
Connections
| Connection 2, width |
40.1 mm |
| Connection, type |
HDMI™ male (type A) |
| Connection, width |
20.4 mm |
| Connection, contact material |
gold (24 kt) |
| Connection, height |
11.4 mm |
| Connection 2, height |
16.8 mm |
| Connection 2, type |
DVI-D male Dual-Link (24+1 pin) |
| Connection 2, length |
51.1 mm |
| Connection, length |
42.1 mm |
| Connection, shielding |
yes |
| Connection, housing material |
PVC |
Cable
| Kink protection |
both sides |
| Cable length |
15 m |
| Number of shieldings |
2 x |
| Type 2, shielding |
braid (copper) 112x |
| inner conductor, core diameter |
0.44 |
| Inner conductor material |
OFC (99,9% oxygen-free copper) |
| Cable sheath diameter (approx.) |
8 mm |
| Inner Conductor number |
1 pieces |
| AWG |
26 |
| Ferrite core |
no |
| Cable type |
round cable |
Signal transmission
| Impedance |
100 Ω |
| max. bandwidth |
195 MHz |
| max. transmission rate |
4.95 Gbit/s |
