Series 1.4
EN High Speed HDMI™ Cable with Ethernet
EN HDMI™ male (type A) > HDMI™ male (type A)
- EN 4K Resolution 30Hz, 3D Resolution (1920x1080p 24Hz)
- integrated Ethernet channel saves additional network or audio cables
- Data rate max. 8,16 Gbit/s (340 MHz × 8 bit × 3)
- supported color space YCC-601, Adobe RGB, Adobe YCC-601
- EN
General
| Markings |
CE, WEEE |
| Diameter |
6 mm |
| max. resolution |
4K Ultra HD 2160p (30 Hz) |
| Color |
silver |
| Consumption Unit |
1 pc. blister |
| Packaging type |
Bulk |
Connections
| Connection, type |
HDMI™ male (type A) |
| Connection, contact material |
nickel |
| Connection 2, type |
HDMI™ male (type A) |
| Connection, housing material |
nickel |
Cable
| Kink protection |
both sides |
| Cable length |
15 m |
| Number of shieldings |
2 x |
| Inner conductor material |
CCS |
| AWG |
28 |
| Ferrite core |
no |
| Cable type |
round cable |
Signal transmission
| other supported standards |
HDR (High Dynamic Range), HDMI™ Ethernet Channel (HEC), 3D, HDCP 2.2, Consumer Electronics Control (CEC), Audio Return Channel (ARC) |
| supported colorspaces |
Deep Color (36 Bit), x.v.Colour (xvYCC) |
| supported audio standards |
Audio Return Channel (ARC) |
| max. transmission rate |
10.2 Gbit/s |
